Teraflex Falcon SP2 3.3 Fast Adjust Piggyback 2"-4.5" Lift Front & Rear Shock Absorber Kit for 2018-2024 Wrangler JL
Overview:
Falcon SP2 3.3 Fast Adjust Piggyback Shocks offer a wide range of adjustability with their easy-to-use 3-position Fast Adjust Knob. Settings include Soft, Custom, and Firm. The Custom setting incorporates an 8-Position Dial for more precise tuning. "High-Value Performance" is the driving force behind our vehicle-specific dampers for Jeeps, trucks, and SUVs. These Jeep-specific shock absorbers deliver increased stability, improved ride quality, and comfort for daily-driven vehicles as well as race-inspired performance, handling, and stability for off-road rigs. Falcon Performance Shocks by TeraFlex. SP2 3.3 Fast Adjust Piggyback Shocks:
- SP2 3.3 Fast Adjust Piggyback Shocks offer a wide range of adjustability for specific terrain and/or handling characteristics
- Fast Adjust Knob w/ 3 compression settings for large damping adjustments
- Settings include: Soft, Medium, Firm
- Custom setting includes an 8-Position Dial for finer damping adjustments
- SP2 Mode Adjust tunes compression and rebound for Soft or Performance settings
- Ideal for daily-driven Jeeps as well as the serious enthusiast wanting to adjust damping for all driving conditions
JL Falcon Shocks:
- JL corner-specific shock absorber w/ race-inspired performance
- Front lower offset eyelet design provides maximum shock body to frame clearance during articulation
- Rear roost guards prevent shock shaft damage from rocks kicked up by the tires
- SP2 Mode Adjust tunes compression and rebound for Soft or Performance settings Falcon Series 3 Piggyback Shocks:
- Piggyback design increases oil and gas capacity for reduced heat
- Flows 6x more oil than restrictive reservoir hose designs
- Eliminates common leakage issues found in banjo and swivel fittings
- Front shocks' unique horizontal piggyback reservoir increases tire clearance
- Cartridge Upgrade Kits are available separately - contact customer service for details
FEATURES/BENEFITS SP2 Mode Adjust Shocks:
- Choose between Soft and Performance modes during install
- Tunes both compression and rebound
- Soft mode allows a partial bypass of the main piston for a softer ride
- During aggressive driving, Soft mode retains performance tuning for optimal handling
- Soft mode recommended for rough terrain/surfaces and cold weather
- Performance mode recommended for max on- and off-road handling, stability, and control
Falcon Performance Shocks (all):
- Vehicle-specific shock absorbers
- Race-inspired performance for increased vehicle stability
- Improved dynamic roll control and low-speed damping
- Dramatic improvement in on-road comfort and off-road performance
- Optimized fitment for unobstructed suspension travel and articulation
- 2.3" shock body provides optimal performance
- 6061-T6 aluminum alloy shock body resists Impact to protect internal components
- Smooth honed internal shock body surface for long-term performance
- 3/4" induction hardened chrome plated shaft resists rock damage, corrosion, and shaft buckling
- Large shaft diameter provides a wide range of adjustment on adjustable shocks
- Hard anodized 6061-T6 aluminum alloy billet piston
- 1-piece Teflon bronze piston wear band w/ O-ring
- VOD (Volume Optimized Damping) features a digressive linear piston for quicker ramp-up and increased damping volume
- VOD reduces shock bottoming at full compression or over uneven terrain
- OGS (Oil/Gas Separator) prevents cavitation
- High-viscosity, full synthetic Red Line shock oil for consistent performance across all temperatures
- Synthetic formula also contains special anti-wear and lubricity agents
- 1,000-hour salt spray corrosion resistance test on all hardware
- Serviceable and rebuildable (factory serviced)
- Designed, engineered, and assembled in-house from domestic and globally sourced components
- Patented design
- 3-year warranty
INCLUDES
- SP2 3.3 Fast Adjust Piggyback Shocks - all 4
- Rear roost guards - pair
- All necessary hardware
VEHICLE FITMENT INFO
- 2-4.5" Lift
PRODUCT NOTES
- Does NOT fit EcoDiesel models.
- Upgradeable to 3.3 Fast Adjust via Cartridge Upgrade Kits for quick compression adjustments. Sold separately - contact customer service for details.
- Bump stop configuration varies depending on shock absorber collapsed length, tire size, and fenders - See instructions for proper configuration for your application.
- May require 2" Bump Stop Strike Pad Extension Kit (# 1959500) and/or 0.5" Bump Stop Strike Pad Shim Kit(s) (# 1959300).
RELATED ITEMS Configurations:
JL 2-Door: 2-3.5" Lift - All 4 (10-02-33-400-200)
JL 4-Door: 2-3.5" Lift - All 4 (11-02-33-400-200)
